Round bellows suction cup Ø 75 mm PUR without connector OGVN-75-A-U - Festo 8204838
The Festo OGVN-75-A-U suction cup (Ø 75 mm, PUR) is the suction element for vacuum grippers, with connecting parts chosen to suit the application. Bellows with 1.5 convolutions and 16 mm height compensation for uneven or inclined surfaces. PUR suction cup, Shore hardness A 70 +/-5.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo OGVN-75-A-U suction cup (Ø 75 mm, PUR) is the suction element for vacuum grippers, with connecting parts chosen to suit the application.
Why choose it
- Bellows with 1.5 convolutions and 16 mm height compensation for uneven or inclined surfaces
- PUR suction cup, Shore hardness A 70 +/-5
- LABS (PWIS) conformity VDMA24364-A1/A2-L
- Suitable for battery production with reduced Cu/Zn/Ni values (F1a)
- Usable at ambient temperatures of 10 to 45 °C
Areas of use
The bellows works on curved, inclined or varying-height workpieces and suits packaging and moulded parts.
Technical data
| Type | OGVN-75-A-U |
|---|---|
| Festo part number | 8204838 |
| Height compensator for suction cup | 16 mm |
| Suction cup diameter | 75 mm |
| Suction cup volume | 42.8 cm³ |
| Position of connection | On top |
| Mounting position | Any |
| Suction cup shape | Round, bellows with 1.5 convolutions |
| Operating pressure | -0.95 to 0 bar |
| Nominal operating pressure | -0.7 bar |
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-A1/A2-L |
| Suitability for the production of Li-ion batteries | Suitable for battery production with reduced Cu/Zn/Ni values (F1a) |
| Ambient temperature | 10 to 45 °C |
| Product weight | 40 g |
| Type of mounting | Via vacuum port |
| Colour | Blue/light blue |
| Shore hardness | A 70 +/-5 |
| Note on materials | RoHS compliant |
| Material suction cup | PUR |
| Weight | 0.055 kg |
| Manufacturer | Festo |
| Hersteller-Nr | OGVN-75-A-U |
| EAN | 4052568929992 |
| Zolltarifnummer | 84799070 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PUR |
| Diameter [mm] | 75 |
| Medium | Air |
| Temperature (max.) | 45 |
