Connecting cable NEBM-T12W4-R-3-LE4 - Festo 8140938
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Based on standard | EN 61076-2-111 |
|---|---|
| Cable designation | With inscription label holder |
| Product weight | 256 g |
| Electrical connection 1, function | Field device side |
| Electrical connection 1, design | Round |
| Electrical connection 1, connection type | Socket |
| Electrical connection 1, cable outlet | Angled |
| Electrical connection 1, connector system | M12x1, T-coded according to EN 61076-2-111 |
| Electrical connection 1, number of connections/cores | 4 |
| Electrical connection 1, used connections/cores | 4 |
| Electrical connection 1, type of mounting | Screw-type lock |
| Electrical connection 1, connection pattern | Socket, M12x1 T-coded according to EN 61076-2-111, 4-pin |
| Electrical connection 2, function | Control side |
| Electrical connection 2, connection type | Cable |
| Electrical connection 2, connector system | Open end |
| Electrical connection 2, number of connections/cores | 4 |
| Electrical connection 2, used connections/cores | 4 |
| Operational voltage range DC | 0 ... 60 V |
| Current rating at 40° C | 5 A |
| Immunity to surge | 1.5 kV |
| Shielding | No |
| Cable length | 3 m |
| Cable characteristic | Suitable for robot applications |
| Test conditions cable | Test conditions on request |
| Bending radius, fixed cable | 30 mm |
| Bending radius, moving cable | 75 mm |
| Cable diameter | 7.5 mm |
| Cable diameter tolerance | ±0.2 mm |
| Cable structure | 4 x 0.75 mm² |
| Nominal cross section conductor | 0.75 mm² |
| Conductor nominal cross section | AWG19 |
| Wire ends | Stripped |
| Degree of protection | IP67 |
| Note on degree of protection | In mounted state |
| Ambient temperature | -40 ... 80 °C |
| Ambient temperature with moving cable | -20 ... 80 °C |
| CE mark (see declaration of conformity) | In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Note on materials | RoHS compliant |
| Pollution degree | 3 |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| Material cable sheath | PVC |
| Cable sheath colour | Black |
| Material housing | TPE-U(PUR) |
| Housing colour | Black |
| Material screw-type lock | High-alloy stainless steel |
| Material seals | HNBR |
| Material electrical contact | Gold-plated brass |
| Material insulating sheath | PVC |
| Weight | 0.26 kg |
| Manufacturer | Festo |
| Hersteller-Nr | NEBM-T12W4-R-3-LE4 |
| EAN | 4052568601577 |
| Zolltarifnummer | 85444290 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
