Power supply unit 48 V DC output, 20 A output current CACN-11A-7-20-G2 - Festo 8149585

Festo ✓ Original product Brand new

Power supply unit CACN-11A-7-20-G2 with 48 V DC output, 20 A output current, 400 to 500 V AC input. The power supply unit supplies controllers and drives with DC voltage. Festo lists the part as an accessory for servo drives. Further data: 3 Phase ~, 25 ms mains buffering.

Net
€801.00
excl. VAT
Item FES-8149585
Manufacturer no. CACN-11A-7-20-G2
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Power supply unit CACN-11A-7-20-G2 with 48 V DC output, 20 A output current, 400 to 500 V AC input. The power supply unit supplies controllers and drives with DC voltage.

Benefits

  • Nominal output voltage DC: 48 V
  • Nominal output current: 20 A
  • Input voltage range AC: 400 to 500 V
  • Primary supply: 3 Phase ~
  • Power failure bridging: 25 ms

Applications

Festo lists the part as an accessory for servo drives. Product weight 2.5 kg, RoHS compliant.

Technical data

Width96 mm
Height130 mm
Length179 mm
Mounting positionOpen convection
Primary supply3 Phase ~
Input current1.7 - 2.1 A
Nominal output voltage DC48 V
Nominal output current20 A
Input voltage range AC400 to 500 V
Power failure bridging25 ms
Mains frequency45 to 65 Hz
Approvalc UL us - Listed (Oil)
CE mark (see declaration of conformity)To EU EMC Directive, To EU Low Voltage Directive
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-40 to 85 °C
Relative air humidity95%
Degree of protectionIP20
Ambient temperature-25 to 70 °C
Product weight2500 g
Type of mountingvia DIN rail
Note on materialsRoHS compliant
Weight2.9 kg
ManufacturerFesto
Hersteller-NrCACN-11A-7-20-G2
EAN4052568572228
Zolltarifnummer85044083
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Protection ratingIP20
Temperature (max.)70
