With 12 stations this multi-pin valve terminal bundles the valves of a machine in one place. The supply is 24 V DC. The materials are body and spool aluminium, seals NBR, pilot polyamide.
Multi-pin valve terminal, 12 stations, G 1/8", 24 V DC, protection class IP 40
E.MC
Original product
Net price (excl. VAT)
€530.68
Item
FL-571044
Manufacturer no.
S1R-06-12
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.S1R-06-12
EAN4050571895389
Customs tariff number84812090
ConditionNew
Artikel
FL-571044
Frequently Bought Together
-
This Item:
€530.68
-
Valve terminal, 10 stations, PROFIBUS, outlets M 7 at valves (top), 20x M 7, 24 V DC
€1,382.09
-
Ventilterminal für BUS-Modul 6x 5/2-Wege, monostabil, M5 von EMC
€342.45
Total price
This multi-pin valve terminal groups 12 valve stations and thus shortens piping and wiring in the control cabinet. The supply is 24 V DC. The protection class is IP 40. The materials are body and spool aluminium, seals NBR, pilot polyamide.
Advantages
- Operating pressure of 1.5 to 8 bar for all stations jointly.
- Materials body and spool aluminium, seals NBR, pilot polyamide, matched to continuous operation at the machine.
- Temperature range of -5 to +60 °C for installation in the machine environment.
- Dimensions A 49, B 29, C 54.7, D 106, E 19, F 20, K 247, L 237, N 4, so the space requirement can be planned in advance.
- Capacity for 12 valve stations, so the terminal grows with the plant.
Technical data
| Feature | Value |
|---|---|
| Number of stations [pcs] | 12 |
| mounted valves | 5/2-way valves with spring return |
| Dimensions [mm] | A 49, B 29, C 54.7, D 106, E 19, F 20, K 247, L 237, N 4 |
| Material body and spool | aluminium |
| Material seals | NBR |
| Material pilot | polyamide |
| Temperature range | -5 to +60 °C |
| Operating pressure | 1.5 to 8 bar |
| Media | oiled and non-oiled, filtered compressed air |
| Switching time (at 5 bar) | below 50 ms, max. 5 switching cycles / sec. (5/3-way: max. 3 switching cycles / sec.) |
| Control voltages | 24 V DC |
| Voltage tolerance | plus/minus 10 percent |
| Protection class | IP 40 |
| Service life | min. 40 million switching cycles |
Applications
- Machines with up to 12 pneumatic axes in one place.
- Retrofitting and extending existing valve islands.
- Special purpose machinery with a changing number of actuators.
| Weight | 2.000000 |
|---|---|
| Manufacturer | E.MC |
| Hersteller-Nr | S1R-06-12 |
| EAN | 4050571895389 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Anzahl Stationen [Stk] | 12 |
