3/2-way solenoid valve, 2x 3/2-way (NO/NO), Half-socket valve, G 1/8", 24 V DC, 700 l/min

A double-acting actuator needs a valve that switches the air path reliably and delivers the required flow. This 3/2-way solenoid valve with connection G 1/8" passes 700 l/min and is controlled with 24 V DC. The switching function is 2x 3/2-way (NO/NO). The actuator can therefore be switched straight from the machine control without an extra pilot stage.

Advantages

• Control voltage tolerance plus/minus 10 percent, which makes short supply dips uncritical.
• Media oiled and non-oiled, filtered compressed air, so no separate treatment is needed.
• Flow rate of 700 l/min, so the connected actuator moves without the valve throttling it.
• Switching function 2x 3/2-way (NO/NO), so the rest position is clearly defined.
• Control with 24 V DC at a power consumption of 0.8 W / valve solenoid, which relieves the supply when many valves share one cabinet.

Applications

• Sequencing of pneumatic axes with connection G 1/8" in handling equipment.
• Installation in control cabinets with a supply of 24 V DC.
• Control of pneumatic flaps, gates and diverters in conveying equipment.
• Cycled feeding and clamping units in fixture building.
