RADEX-N 85 Lamellenpaket rostfrei - KTR 710859200001
RADEX-N 85 Lamellenpaket rostfrei. RADEX-N is a backlash-free, torsionally stiff all-steel laminae coupling from KTR.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
RADEX-N is a backlash-free, torsionally stiff all-steel laminae coupling from KTR. Laminae packs are bolted to hubs and spacer by friction and positive fit.
Benefits
- Backlash-free and torsionally stiff for high torque
- Maintenance-free and wear-free without elastomer
Version
RADEX-N 85 Lamellenpaket rostfrei.
Applications
Torsionally rigid connection in pump, gearbox and machine drives.
Technical data
| Weight | 1.01 kg |
|---|---|
| Manufacturer | KTR |
| Hersteller-Nr | 710859200001 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | KTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Series | RADEX |
