Foot flange PTFS 400 in ductile cast iron GGG for motor and pump carrier, size 400 - KTR 114004200000

Fußflansch PTFS 400 GGG - KTR 114004200000

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Foot flange PTFS 400 in ductile cast iron GGG for motor and pump carrier, size 400 - KTR 114004200000

KTR ✓ Original product Brand new Made in Germany

The foot flange PTFS 400 GGG puts the unit of electric motor and pump carrier of size 400 on feet and so allows horizontal mounting. Made of ductile cast iron, weight 21 kg. Part of the KTR range for hydraulic power units.

Net

€413.84

excl. VAT

Item KTR-114004200000

Manufacturer no. 114004200000

Question about this item

Datasheet (PDF) 45 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

KTR foot flange PTFS 400 GGG in size 400, made of ductile cast iron. It carries motor and pump carrier of size 400 in a horizontal arrangement.

Benefits

Foot mounting for size 400
Horizontal mounting of motor and pump carrier
Material ductile cast iron (GGG)
Weight 21 kg

Applications

Hydraulic power units with a pump carrier of size 400 whose drive is installed horizontally. Check type PTFS 400 GGG against motor and pump carrier before ordering.

Technical data

Series	Foot flange PTFS
Type	PTFS 400 GGG
Size	400
Material	ductile cast iron (GGG)
Weight	21 kg
KTR article number	114004200000
HS code	84139100
Manufacturer	KTR
Hersteller-Nr	114004200000
Zolltarifnummer	84139100
GPSR Herstellerdaten	KTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
