Compact flow control valve, supply and exhaust air control, G 1/4", tube 6 mm, -0.95 bar

Screwed directly into the cylinder port, a function fitting saves tubing and space. This compact flow control valve takes the thread G 1/4" and leads to a tube of 6 mm outside diameter. The push-in connector holds the tube with stainless steel gripping claws. The materials are body Nickel-plated brass / PA 66, release ring PA 66, seal NBR, retaining claws stainless steel, cartridge ZnDC zinc-plated. The operating pressure is stated as -0.95 bar.

Advantages

• Operating pressure of -0.95 bar, which states the permissible range.
• Temperature range of -20 to +80 °C, suitable for production environments with changing load.
• Media Compressed air, neutral gases, the valve needs no separate treatment.
• Version supply and exhaust air control, so the speed is limited on the correct side of the piston.
• Push-in connector for tube with 6 mm outside diameter, release works without tools through the release ring.

Applications

• Screwing directly into cylinder end caps with thread G 1/4".
• Avoiding the stick-slip effect on slow running actuators.
• Matching forward and return stroke in cycled handling devices.
• Production environments within the temperature range -20 to +80 °C.
