Suction cup fixations, Type G, G 1/4" (AG)

Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.

This suction cup holder connects the suction cup to the vacuum line by a thread. What counts here is a nominal width of 4 mm. Dimension thread G 1/4" (male thread), nominal width DN 4 mm, height H2 12.0 mm.

Aluminium suction cup holder, type G, thread G 1/4" (male thread), nominal width DN 4 mm

Name: Aluminium suction cup holder, type G, thread G 1/4" (male thread), nominal width DN 4 mm
Brand: Fluidics equipment
SKU: FL-228823
Price: 2.16 EUR
Availability: InStock

FLUIDICS EQUIPMENT Original product

Net price (excl. VAT)

€2.16

Item FL-228823

Manufacturer no. VSH G14

Personal expert advice

Brand new Specialist dealer since 2009 Original product Worldwide shipping

Product data

Manufacturer no.VSH G14

EAN4050571726331

Customs tariff number76161000

ConditionNew

Artikel

FL-228823

Frequently Bought Together

This Item: Aluminium suction cup holder, type G, thread G 1/4" (male thread), nominal width DN 4 mm
€2.16
Vacuum filter for the hose line, for hose outside diameter 6 mm, suction rate 50 l/min
€44.18
Flat suction cup, Ø 70 mm, stroke 6 mm, silicone, 50 Shore A, transparent, fine lip
€32.16

Total price

Details

Once installed, the suction cup holder connects the suction cup to the vacuum line by a thread. It is supplied with thread G 1/4" (male thread), nominal width DN 4 mm and height H2 12.0 mm.

Benefits

Nominal width DN of 4 mm as per the data sheet.
Listed with Dimension D1 8.6 mm.
Dimension D2 13.0 mm.
Width across flats SW of 17 mm as per the data sheet.
Listed with Dimension H1 2.3 mm.

Technical data

Version	aluminium suction cup holder
Holder type	G
Thread G	G 1/4" (male thread)
Nominal width DN [mm]	4
Dimension D1 [mm]	8.6
Dimension D2 [mm]	13.0
Width across flats SW [mm]	17
Dimension H1 [mm]	2.3
Dimension H2 [mm]	12.0
Dimension H3 [mm]	27.0
Form number	1

Applications

Typical use is anywhere the suction cup holder has to connect the suction cup to the vacuum line.

Information

More Information
Hersteller-Nr	VSH G14
Manufacturer	Fluidics equipment
EAN	4050571726331
Weight	0.007000
Zolltarifnummer	76161000
GPSR Herstellerdaten	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität	Original product
Artikelzustand	New
Position sensing	No
