This bellows suction cup holds the workpiece on the suction face by vacuum. What counts here is a suction cup diameter of 10 mm. Material silicone, 65 Shore A, size Ø 10 mm, stroke 4 mm, holder type F, colour red.
Bellows suction cup for vacuum handling, Ø 10 mm, stroke 4 mm, silicone, 65 Shore A
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€4.21
Item
FL-228777
Manufacturer no.
VS 10 B2 SI
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VS 10 B2 SI
EAN4050571723514
Customs tariff number84879090
ConditionNew
Artikel
FL-228777
Frequently Bought Together
The bellows suction cup holds the workpiece on the suction face by vacuum. In addition the sheet lists a stroke of 4 mm. Its rating is a suction cup diameter of 10 mm.
Benefits
- Listed with Suction cup diameter D Ø 10 mm.
- Stroke 4 mm.
- Dimension D1 of 5 mm as per the data sheet.
- Listed with Dimension D2 10 mm.
- Dimension D3 6 mm.
Technical data
| Material | silicone, 65 Shore A |
|---|---|
| Suction cup diameter D [mm] | Ø 10 |
| Stroke [mm] | 4 |
| Colour | red |
| Connection (female thread) | G 1/8" |
| Connection (male thread) | G 1/8" |
| Dimension D1 [mm] | 5 |
| Dimension D2 [mm] | 10 |
| Dimension D3 [mm] | 6 |
| Dimension h [mm] | 14 |
| Suction cup height H [mm] | 26.5 |
| Temperature range [°C] | -40 to +200 |
| Holder type | F |
| Bellows form | 2.5 folds |
Applications
Typical use is anywhere the bellows suction cup has to pick up and hold workpieces by vacuum.
| Hersteller-Nr | VS 10 B2 SI |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571723514 |
| Weight | 0.000800 |
| Zolltarifnummer | 84879090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
