Bellows suction cup for vacuum handling, Ø 30 mm, stroke 13 mm, silicone, 65 Shore A
This bellows suction cup holds the workpiece on the suction face by vacuum. A key figure is a suction cup diameter of 30 mm. Size Ø 30 mm, stroke 13 mm, holder type G, colour red, material silicone, 65 Shore A.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Once installed, the bellows suction cup holds the workpiece on the suction face by vacuum. The data state a suction cup diameter of 30 mm. This version is listed with suction cup diameter 30 mm, stroke 13 mm, holder type G and colour red. Material silicone, 65 Shore A is listed for this version.
Benefits
- Listed with Suction cup diameter D Ø 30 mm.
- Stroke 13 mm.
- Dimension D1 of 8 mm as per the data sheet.
- Listed with Dimension D2 19 mm.
- Dimension D3 12 mm.
Applications
The bellows suction cup is used wherever it has to pick up and hold workpieces by vacuum.
Technical data
| Material | silicone, 65 Shore A |
|---|---|
| Suction cup diameter D [mm] | Ø 30 |
| Stroke [mm] | 13 |
| Colour | red |
| Connection (female thread) | G 1/4" |
| Connection (male thread) | G 1/4" |
| Dimension D1 [mm] | 8 |
| Dimension D2 [mm] | 19 |
| Dimension D3 [mm] | 12 |
| Dimension h [mm] | 33 |
| Suction cup height H [mm] | 48 |
| Temperature range [°C] | -40 to +200 |
| Holder type | G |
| Bellows form | 2.5 folds |
| Weight | 0.01 kg |
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | VS 30 B2 SI |
| EAN | 4050571724740 |
| Zolltarifnummer | 84879090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
