In service the vacuum ejector produces the handling vacuum from compressed air on the venturi principle. The decisive figure is a suction rate of 2100 l/min. The dimensions come to vacuum port G 1-1/2", suction rate 2100 l/min, vacuum up to 70 %.
Multi-stage vacuum ejector, vacuum up to 70 %, vacuum port G 1-1/2", suction rate 2100 l/min
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€1,595.37
€1,340.65
Item
FL-016023
Manufacturer no.
VLP 32
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VLP 32
EAN4050571722630
Customs tariff number84141089
ConditionNew
Artikel
FL-016023
Frequently Bought Together
-
This Item:
€1,595.37 €1,340.65
-
Bellows suction cup for vacuum handling, Ø 6 mm, stroke 2 mm, silicone, 50 Shore A
€3.51 €2.95
-
3/2-way vacuum valve, port G 3/8", nominal width DN 11 mm, control voltage 230 V AC
€1,361.24 €1,143.90
This vacuum ejector produces the handling vacuum from compressed air on the venturi principle. The data sheet gives a suction rate of 2100 l/min.
Benefits
- Suction rate 2100 l/min.
- Air consumption of 700 l/min as per the data sheet.
- Listed with Length L 250 mm.
- Width B 97 mm.
- Height H of 65 mm as per the data sheet.
Technical data
| Suction rate [l/min] | 2100 |
|---|---|
| Compressed air thread | G 3/8" |
| Vacuum thread | G 1-1/2" |
| Exhaust thread | G 1-1/2" |
| Air consumption [l/min] | 700 |
| Length L [mm] | 250 |
| Width B [mm] | 97 |
| Height H [mm] | 65 |
| Evacuation time down to 10 percent vacuum [s/l] | 0.0030 |
| Evacuation time down to 20 percent vacuum [s/l] | 0.0100 |
| Evacuation time down to 30 percent vacuum [s/l] | 0.0200 |
| Evacuation time down to 40 percent vacuum [s/l] | 0.040 |
| Evacuation time down to 50 percent vacuum [s/l] | 0.060 |
| Evacuation time down to 60 percent vacuum [s/l] | 0.100 |
| Evacuation time down to 70 percent vacuum [s/l] | 0.180 |
| Flow rate at 0 percent vacuum [l/min] | 2.100 |
| Flow rate at 10 percent vacuum [l/min] | 1.360 |
| Flow rate at 20 percent vacuum [l/min] | 840 |
| Flow rate at 30 percent vacuum [l/min] | 520 |
| Flow rate at 40 percent vacuum [l/min] | 360 |
| Flow rate at 50 percent vacuum [l/min] | 300 |
| Flow rate at 60 percent vacuum [l/min] | 200 |
| Temperature range [°C] | -10 to +100 |
| Nozzle material | brass |
| Seals | Neopren |
| Vacuum level [%] | 70 |
Applications
The vacuum ejector is used wherever it has to produce a vacuum from compressed air.
| Hersteller-Nr | VLP 32 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571722630 |
| Weight | 2.600000 |
| Zolltarifnummer | 84141089 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
