This rod end links the piston rod to the load so that it can pivot. What counts here is the piston rod thread M 12. Material zinc-plated steel, size 12 x 22 x 50 mm.
Rod end, for piston rod thread M 12, zinc-plated steel, dimension D 12 mm, dimension L 22 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€24.38
Item
FL-013317
Manufacturer no.
SGS M12
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SGS M12
EAN4050571625511
Customs tariff number73269098
ConditionNew
Artikel
FL-013317
Frequently Bought Together
Once installed, the rod end links the piston rod to the load so that it can pivot. It is supplied with 12 mm for dimension D, 22 mm for dimension L and 50 mm for dimension H. The article is made of zinc-plated steel.
Benefits
- Fits the piston rod thread M 12.
- Material zinc-plated steel for piston rod thread M 12.
- Dimension D comes to 12 mm.
- Dimension L comes to 22 mm.
- Dimension C comes to 12.00 mm.
Technical data
| Material | zinc-plated steel |
|---|---|
| For piston rod thread A | M 12 |
| Dimension B [mm] | 16 |
| Dimension C [mm] | 12.00 |
| Dimension D [mm] | 12 |
| Dimension D2 [mm] | 32 |
| Dimension L [mm] | 22 |
| Dimension H [mm] | 50 |
Applications
In feed and clamping equipment the rod end sits on thread M 12.
| Hersteller-Nr | SGS M12 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571625511 |
| Weight | 0.110000 |
| Zolltarifnummer | 73269098 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
