Yoke, with bolts, external male thread M 12, zinc plated steel
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
This clevis head links the piston rod to the load through clevis and pin. What counts here is the piston rod thread M 12. The dimensions come to 82 x 30 x 33 mm.

Clevis head with pin and male thread, for piston rod thread M 12

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€23.16 €19.46
Item FL-045857
Manufacturer no. GAKA M12
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.GAKA M12
EAN4050571314521
Customs tariff number73181595
ConditionNew
Add to Wish List Add to Compare
Artikel
FL-045857
Frequently Bought Together

Once installed, the clevis head links the piston rod to the load through clevis and pin. This version is listed with 82 mm for dimension F, 30 mm for dimension GL and 33 mm for dimension D. Decisive for the selection is the piston rod thread M 12.

Benefits

  • Fits the piston rod thread M 12.
  • Dimension GL comes to 30 mm.
  • Dimension F comes to 82 mm.
  • Dimension D comes to 33 mm.
  • Dimension B of 24 mm as per the data sheet.

Technical data

For piston rod thread AM 12
Dimension B [mm]24
Dimension C [mm]68
Dimension D [mm]33
Dimension E [mm]12
Dimension F [mm]82
Dimension G [mm]24
Dimension H [mm]12
Dimension GL [mm]30

Applications

In feed and clamping equipment the clevis head sits on thread M 12.

More Information
Hersteller-Nr GAKA M12
Manufacturer Fluidics equipment
EAN 4050571314521
Weight 0.155000
Zolltarifnummer 73181595
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Original product
Artikelzustand New
Position sensing No
