This rod end links the piston rod to the load so that it can pivot. A key figure is the piston rod thread M 10. Size 10 x 20 x 43 mm, material zinc-plated steel.
Rod end, for piston rod thread M 10, zinc-plated steel, dimension D 10 mm, dimension L 20 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€18.76
Item
FL-013315
Manufacturer no.
SGS M10
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SGS M10
EAN4050571625498
Customs tariff number73269098
ConditionNew
Artikel
FL-013315
Frequently Bought Together
-
This Item:
€18.76
-
Flexo coupling M 16x1,5, Zinc plated steel
€65.28
-
Angled rod end, for piston rod thread M 12x1.25, dimension L 66.0 mm
€60.34
Total price
As a rod end the article links the piston rod to the load so that it can pivot. This version comes with 10 mm for dimension D, 20 mm for dimension L and 43 mm for dimension H.
Benefits
- Fits the piston rod thread M 10.
- Material zinc-plated steel for piston rod thread M 10.
- Dimension D comes to 10 mm.
- Dimension L comes to 20 mm.
- Dimension C comes to 10.50 mm.
Technical data
| Material | zinc-plated steel |
|---|---|
| For piston rod thread A | M 10 |
| Dimension B [mm] | 14 |
| Dimension C [mm] | 10.50 |
| Dimension D [mm] | 10 |
| Dimension D2 [mm] | 28 |
| Dimension L [mm] | 20 |
| Dimension H [mm] | 43 |
Applications
On a cylinder with piston rod thread M 10 the rod end makes the link to the load.
| Hersteller-Nr | SGS M10 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571625498 |
| Weight | 0.075000 |
| Zolltarifnummer | 73269098 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
