High Tonnage Hydraulic Cylinder, 550 kN, 150 mm Stroke - Enerpac HCR506

The HCR506 delivers 550 kN of pressing force over a 150 mm stroke and is built for heavy lifting and positioning work. Replaceable upper and lower bearings guide the plunger across the full stroke for stable running even under side load.

Benefits

• Fast advance and retract for short cycle times
• Up to 10% side-load resistance over the full cylinder capacity
• Hardened surface resists side loading and cyclic wear
• Weather-protected design for indoor and outdoor use
• Replaceable upper and lower bearings for stability throughout the stroke
• Certified lifting eyes, base mounting holes and collar threads

Technical data

• Pressing force: 550 kN
• Stroke: 150 mm
• Operating pressure: 700 bar
• Weight: 25 kg
• Series: HCR

Applications

Suited to heavy lifting, pressing and positioning tasks in plant, machinery and bridge construction. The high side-load resistance and certified anchor points support use under demanding conditions.
