Gear unit EMGA-40-A-G5-40P - Festo 8085343
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Gear unit flange size | 40 mm |
|---|---|
| Motor flange size | 40 mm |
| Torsional backlash | 0.35 deg |
| Type of gear unit | Right-angle gear unit |
| Gear unit ratio | 5:1 |
| Max. drive speed | 18000 1/min |
| Operating temperature of gear unit | -25 ... 90 °C |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Degree of protection | IP54 |
| Continuous output torque | 7.5 Nm |
| Mass moment of inertia of gear unit | 0.035 kgcm² |
| Max. output torque | 12 Nm |
| Max. efficiency | 95 % |
| Torsional rigidity | 0.8 Nm/arcmin |
| Product weight | 500 g |
| Permissible axial shaft load | 200 N |
| Permissible radial shaft load | 200 N |
| Gear unit interface, output shaft | 40G |
| Gear unit interface, drive shaft | 40P |
| Note on materials | RoHS compliant |
| Weight | 0.7 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EMGA-40-A-G5-40P |
| EAN | 4052568450885 |
| Zolltarifnummer | 84834090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
