Electric parallel gripper size 25, stroke per jaw 16 mm EHPS-25-A - Festo 8070830
With 312 N total gripping force, the parallel gripper EHPS-25-A grips electrically without compressed air. 16 mm stroke per jaw, repetition accuracy 0.01 mm, plain-bearing guide. Supplied with 24 V DC, degree of protection IP40. Position detection with proximity switches.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The size 25 parallel gripper EHPS-25-A delivers 312 N total gripping force. An electric motor moves both jaws in parallel. Version EHPS-25-A: plain-bearing guide, rack and pinion.
Benefits
- 312 N total gripping force
- Repetition accuracy 0.01 mm, replacement accuracy 0.2 mm
- 16 mm stroke per jaw, with max. 230 g per external gripper finger
- Cycle frequency up to 0.8 Hz, current consumption max. 2000 mA
- Corrosion resistance class CRC 1, ambient temperature 5 to 60 °C
Applications
The EHPS-25-A suits handling tasks without a compressed air supply and applications where the controller sets gripping position and gripping force. Gripper fingers are mounted on the jaws, each external finger may weigh up to 230 g. Position detection with proximity switches. Shipping weight 1.1 kg.
Technical data
| Size | 25 |
|---|---|
| Stroke per gripper jaw | 16 mm |
| Max. replacement accuracy | 0.2 mm |
| Max. angular gripper jaw backlash ax, ay | 0.3° |
| Max. gripper jaw backlash Sz | 0.04 mm |
| Rotational symmetry | 0.2 mm |
| Repetition accuracy, gripper | 0.01 mm |
| Number of gripper jaws | 2 |
| Drive system | Electrical |
| Mounting position | Any |
| Gripper function | Parallel |
| Design | Worm gear unit, T-shape, Rack and pinion, Electric gripper |
| Conforms to standard | IEC 61010-1 |
| Guide | Plain-bearing guide |
| Position detection | Via proximity switch |
| Type of motor | DC servo motor |
| Operator controls | Latching switch |
| Ready status indication | LED |
| Max. cycle frequency | 0.8 Hz |
| Max. mass per external gripper finger | 230 g |
| Max. current consumption | 2000 mA |
| Nominal operating voltage DC | 24 V |
| Permissible voltage fluctuations | ±10% |
| Approval | RCM |
| KC mark | KC-EMV |
| CE mark (see declaration of conformity) | To EU EMC Directive, In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Suitability for the production of Li-ion batteries | Copper content max. 5 % by mass (except PCBs, cables, connectors and coils) |
| Sound pressure level | 70 dB(A) |
| Degree of protection | IP40 |
| Ambient temperature | 5 to 60 °C |
| Total gripping force | 312 N |
| Mass moment of inertia | 5.24 kgcm² |
| Max. force on gripper jaw Fz static | 450 N |
| Max. torque at gripper Mx static | 28 Nm |
| Max. torque at gripper My static | 16 Nm |
| Max. torque at gripper Mz static | 28 Nm |
| Lubrication interval for guide components | 2 million cycles |
| Product weight | 904 g |
| Electrical connection | 5-pin, Cable with plug, M12x1 |
| Type of mounting | Via female thread and centring sleeve, Via through-hole and centring sleeve |
| Note on materials | RoHS compliant |
| Housing material | Anodised aluminium |
| Gripper jaw material | High-alloy stainless steel |
| Weight | 1.1 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EHPS-25-A |
| EAN | 4052568445744 |
| Zolltarifnummer | 84798997 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Aluminium |
| Actuation type | Electrical |
| Operating voltage | 24 V DC |
| Protection rating | IP40 |
| Temperaturbereich | 5-60 °C |
| Temperature (max.) | 60 |
