Electric parallel gripper size 16, stroke per jaw 10 mm EHPS-16-A - Festo 8070832

Festo ✓ Original product Brand new

The parallel gripper EHPS-16-A grips electrically without compressed air and delivers 154 N total gripping force. 10 mm stroke per jaw, repetition accuracy 0.03 mm, plain-bearing guide. Supplied with 24 V DC, degree of protection IP40. Position detection with proximity switches.

Net
€1,241.33
excl. VAT
Item FES-8070832
Manufacturer no. EHPS-16-A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The size 16 parallel gripper EHPS-16-A delivers 154 N total gripping force. An electric motor moves both jaws in parallel. Version EHPS-16-A: plain-bearing guide, rack and pinion.

Benefits

  • 154 N total gripping force
  • Repetition accuracy 0.03 mm, replacement accuracy 0.2 mm
  • 10 mm stroke per jaw, with max. 100 g per external gripper finger
  • Cycle frequency up to 1.1 Hz, current consumption max. 1000 mA
  • Corrosion resistance class CRC 1, ambient temperature 5 to 60 °C

Applications

The EHPS-16-A suits handling tasks without a compressed air supply and applications where the controller sets gripping position and gripping force. Gripper fingers are mounted on the jaws, each external finger may weigh up to 100 g. Position detection with proximity switches. Shipping weight 0.48 kg.

Technical data

Size16
Stroke per gripper jaw10 mm
Max. replacement accuracy0.2 mm
Max. angular gripper jaw backlash ax, ay0.4°
Max. gripper jaw backlash Sz0.05 mm
Rotational symmetry0.2 mm
Repetition accuracy, gripper0.03 mm
Number of gripper jaws2
Drive systemElectrical
Mounting positionAny
Gripper functionParallel
DesignWorm gear unit, T-shape, Rack and pinion, Electric gripper
Conforms to standardIEC 61010-1
GuidePlain-bearing guide
Position detectionVia proximity switch
Type of motorDC servo motor
Operator controlsLatching switch
Ready status indicationLED
Max. cycle frequency1.1 Hz
Max. mass per external gripper finger100 g
Max. current consumption1000 mA
Nominal operating voltage DC24 V
Permissible voltage fluctuations±10%
ApprovalRCM
KC markKC-EMV
CE mark (see declaration of conformity)To EU EMC Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)To UK RoHS instructions
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B2-L
Suitability for the production of Li-ion batteriesCopper content max. 5 % by mass (except PCBs, cables, connectors and coils)
Sound pressure level70 dB(A)
Degree of protectionIP40
Ambient temperature5 to 60 °C
Total gripping force154 N
Mass moment of inertia0.78 kgcm²
Max. force on gripper jaw Fz static200 N
Max. torque at gripper Mx static7 Nm
Max. torque at gripper My static4.4 Nm
Max. torque at gripper Mz static7 Nm
Lubrication interval for guide components2 million cycles
Product weight296 g
Electrical connection5-pin, Cable with plug, M12x1
Type of mountingVia female thread and centring sleeve, Via through-hole and centring sleeve
Note on materialsRoHS compliant
Housing materialAnodised aluminium
Gripper jaw materialHigh-alloy stainless steel
Weight0.48 kg
ManufacturerFesto
Hersteller-NrEHPS-16-A
EAN4052568445768
Zolltarifnummer84798997
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
Actuation typeElectrical
Operating voltage24 V DC
Protection ratingIP40
Temperaturbereich5-60 °C
Temperature (max.)60
