Mini slide with ball screw, size 60, stroke 50 mm, lead 5 mm/rev EGSC-BS-KF-60-50-5P - Festo 8162086

Festo ✓ Original product Brand new

Guided linear motion in a small space: the EGSC-BS-KF-60-50-5P moves up to 25 kg with ±0.015 mm repetition accuracy over a 50 mm stroke. Drive with stepper or servo motor via interface T42.

Net
€661.57
excl. VAT
Item FES-8162086
Manufacturer no. EGSC-BS-KF-60-50-5P
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The EGSC-BS-KF-60-50-5P mini slide combines a ball screw with 12 mm spindle diameter and a recirculating ball bearing guide in a flat aluminium housing. With a 50 mm stroke it reaches up to 0.25 m/s and ±0.015 mm repetition accuracy.

Benefits

  • Repeatable: ±0.015 mm at up to 0.25 m/s and a maximum of 3000 1/min.
  • Guided load capacity: transverse force Fy up to 4937 N, torque My up to 30 Nm, payload up to 25 kg.
  • Flexible motor mounting: interface T42 for stepper or servo motor, referencing via fixed stop or reference switch.
  • Quiet and clean: 55 dB(A) sound pressure level, Class 9 according to ISO 14644-1, suitable for battery production (F1a).
  • Durable: lifetime lubrication, 5000 km reference service life, product weight 2030 g.

Applications

The EGSC-BS-KF-60-50-5P suits compact handling axes and pick-and-place tasks. End positions are sensed via proximity switches, the permissible range is 0 to 50 °C.

Technical data

Working stroke50 mm
Size60
Stroke reserve0 mm
Reversing backlash theoretical150 µm
Spindle diameter12 mm
Spindle pitch5 mm/rev
Mounting positionAny
GuideRecirculating ball bearing guide
DesignWith ball screw
Type of motorStepper motor, Servo motor
ReferencingPositive fixed stop block, Negative fixed stop block, Reference switch
Spindle typeBall screw
Position detectionVia proximity switch
Maximum acceleration5 m/s²
Maximum rotational speed3000 1/min
Maximum speed0.25 m/s
Repetition accuracy±0.015 mm
Duty cycle100%
Corrosion resistance class CRC0 - No corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Suitability for the production of Li-ion batteriesSuitable for battery production with reduced Cu/Zn/Ni values (F1a)
Cleanroom suitability, measured according to ISO 14644-14Class 9 according to ISO 14644-1
Sound pressure level55 dB(A)
Degree of protectionIP40
Ambient temperature0 to 50 °C
Impact energy in end positions0.000044 J
Note on the impact energy in the end positionsAt maximum homing speed of 0.01 m/s
Dynamic basic load rating fixed bearing13321 N
Dynamic basic load rating linear guide13400 N
Dynamic basic load rating ball screw5900 N
Idle torque at vmax0.125 Nm
Idle torque at vmin0.032 Nm
Maximum force Fy4937 N
Maximum force Fz4937 N
Fy at theoretical life value of 100 km (only guide consideration)13400 N
Fz at theoretical life value of 100 km (only guide consideration)13400 N
Maximum moment Mx20 Nm
Maximum moment My30 Nm
Maximum moment Mz30 Nm
Mx at theoretical life value of 100 km (only guide consideration)107 Nm
My at theoretical life value of 100 km (only guide consideration)117 Nm
Mz at theoretical life value of 100 km (only guide consideration)117 Nm
Maximum radial force at drive shaft230 N
Maximum feed force Fx250 N
Reference value effective load, horizontal25 kg
Reference value effective load, vertical25 kg
Static basic load rating ball screw10600 N
Static basic load rating linear guide26900 N
Mass moment of inertia JH per metre of stroke0.11539 kgcm²
Mass moment of inertia JL per kg of working load0.00633 kgcm²
Mass moment of inertia JO0.06624 kgcm²
Feed constant5 mm/rev
Static basic load rating fixed bearing7000 N
Reference service life5000 km
Maintenance intervalLifetime lubrication
Moving mass for 0 mm stroke675 g
Additional moving mass per 10 mm stroke40 g
Product weight2030 g
Basic weight for 0 mm stroke1555 g
Additional weight per 10 mm stroke95 g
Type of mountingWith female thread, With centring sleeve, With accessories, Via cylindrical dowel pin
Interface code, actuatorT42
Note on materialsRoHS compliant
Material guide slideBearing steel
Material guide railBearing steel
Material housingAnodised wrought aluminium alloy
Material yoke plateAnodised wrought aluminium alloy
Material piston rodHigh-alloy stainless steel
Material slideAnodised wrought aluminium alloy
Material ball screw nutBearing steel
Material spindleBearing steel
ManufacturerFesto
Hersteller-NrEGSC-BS-KF-60-50-5P
EAN4052568588274
Zolltarifnummer84799070
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Stroke [mm]50
Housing materialAluminium, anodised
SeriesEGSC
Protection ratingIP40
Temperaturbereich0-50 °C
Temperature (max.)50
