Coupling Ø 19 / 22 mm, 60 Nm EAMC-56-58-19-22 - Festo 8099430

Festo ✓ Original product Brand new

The Festo coupling EAMC-56-58-19-22 transmits the torque between motor shaft and drive shaft. Transmits up to 60 Nm of torque between motor and drive, plus mounting diameters of 19 mm and 22 mm for the two shafts. Speeds up to 5500 1/min permitted. Genuine Festo accessory.

Net
€121.53
excl. VAT
Item FES-8099430
Manufacturer no. EAMC-56-58-19-22
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The coupling EAMC-56-58-19-22 transmits the torque between motor shaft and drive shaft. The key values: Ø 19 / 22 mm, 60 Nm, size 56.

Benefits

  • Transmits up to 60 Nm of torque between motor and drive
  • Mounting diameters of 19 mm and 22 mm for the two shafts
  • Speeds up to 5500 1/min permitted
  • Mass moment of inertia of 128 kgmm² for motor sizing
  • Nominal length of 58 mm
  • Suitable for ambient temperatures of -25 to 60 °C

Application

The shaft diameters of motor and drive must match the mounting bores of the EAMC-56-58-19-22. EAMC-56-58-19-22 can be installed in any mounting position at ambient temperatures of -25 to 60 °C.

Technical data

FeatureValue
TypeEAMC-56-58-19-22
Festo part number8099430
Mounting diameter 119 mm
Mounting diameter 222 mm
Size56
Nominal length58 mm
Mounting positionany
Max. rotational speed5500 1/min
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-25 to 60 °C
Relative air humidity0 to 95 %
Ambient temperature-25 to 60 °C
Mass moment of inertia128 kgmm²
Transmittable torque60 Nm
Product weight283 g
Note on materialsRoHS compliant
Weight0.33 kg
ManufacturerFesto
Hersteller-NrEAMC-56-58-19-22
EAN4052568452971
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMC
Temperature (max.)60
