Axial kit for motor mounting, actuator T46, motor 60RA, 10 Nm EAMM-A-T46-60RA - Festo 8126175

Festo ✓ Original product Brand new

The axial kit EAMM-A-T46-60RA mounts a motor with interface 60RA in line with a drive carrying interface code T46. It transmits up to 10 Nm. Speed up to 8000 1/min, degree of protection IP40. Mass moment of inertia 3.2 kgmm².

Net
€96.23
excl. VAT
Item FES-8126175
Manufacturer no. EAMM-A-T46-60RA
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo axial kit EAMM-A-T46-60RA connects a motor with interface code 60RA coaxially to an electric drive with interface T46. Transmittable torque is 10 Nm, maximum speed 8000 1/min.

Benefits

  • Transmittable torque 10 Nm between motor and drive
  • Speed up to 8000 1/min
  • Mass moment of inertia 3.2 kgmm² as input for drive sizing
  • Interfaces actuator T46, motor 60RA
  • Degree of protection IP40, ambient temperature -10 to 60 °C

Applications

The kit sits between motor and electric drive, for example when building handling systems, gantries and feeders. On the drive side it fits interface code T46, on the motor side 60RA.

Technical data

Nominal length47 mm
Mounting positionAny
Max. rotational speed8000 1/min
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-25 to 60 °C
Relative air humidity0 - 95%
Degree of protectionIP40
Ambient temperature-10 to 60 °C
Mass moment of inertia3.2 kgmm²
Transmittable torque10 Nm
Product weight399 g
Interface code, actuatorT46
Interface code, motor in60RA
Note on materialsRoHS compliant
ManufacturerFesto
Hersteller-NrEAMM-A-T46-60RA
EAN4052568557614
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich-10-60 °C
Temperature (max.)60
