Manifold block CAPS-M1-VDE1-S-A-AL-N14 - Festo 8154578
Net
excl. VAT
€88.10
Item
FES-8154578
Manufacturer no.
CAPS-M1-VDE1-S-A-AL-N14
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Dimensions (W x L x H) | 65 mm x 104 mm x 28 mm |
|---|---|
| Mode of operation | Single-acting |
| Design characteristics | Safety pneumatic output 2 exhausted |
| Standard nominal flow rate (standardised to DIN 1343) | 380 l/min |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Product weight | 465 g |
| Type of mounting | in accordance with VDI/VDE 3845 |
| Pneumatic connection | 1/4 NPT |
| Note on materials | RoHS compliant |
| Material screws | High-alloy stainless steel |
| Material housing | Aluminium, powder-coated |
| Weight | 0.5 kg |
| Manufacturer | Festo |
| Hersteller-Nr | CAPS-M1-VDE1-S-A-AL-N14 |
| EAN | 4052568577230 |
| Zolltarifnummer | 76169990 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
