Double-acting compact cylinder Ø 80 mm stroke 135 mm ADN-80-135-I-P-A - Festo 609115

Ø 80 mm piston, 135 mm stroke: the double-acting compact cylinder ADN-80-135-I-P-A from the ADN series is the Festo version with part number 609115. The letter A after the cushioning code in type ADN-80-135-I-P-A stands for position detection via proximity switches. Compressed air drives the piston both ways, so advance and return over 135 mm are powered.

Benefits

• Piston Ø 80 mm, stroke 135 mm
• Elastic end-position cushioning P at both ends
• Piston rod with female thread
• End positions can be sensed with proximity switches
• Double-acting: force in both directions
• Weight 2.2 kg

Applications

In handling and fixture construction the cylinder moves parts over 135 mm, for example as an ejector, pusher or lifting unit.
