Compact cylinder double-acting Ø 25 mm stroke 25 mm ADN-S-25-25-A-P - Festo 8092092

Where space in the stroke direction is short, the ADN-S-25-25-A-P fits in: double-acting compact cylinder, 25 mm piston, 25 mm stroke, 295 N advance and 247 N return force at 6 bar.

Key benefits

• Easy sizing: 295 N forward and 247 N back at 6 bar according to Festo
• Quiet stop: elastic cushioning at both ends absorbs 0.18 J in the end positions
• Flexible use: operating pressure 0.6 to 10 bar, any mounting position
• Corrosion resistance class CRC 1: piston rod in high-alloy stainless steel
• Cleanroom and paint shops: class 5 to ISO 14644-1, LABS (PWIS) conformity VDMA24364-B2-L

Applications

Typical tasks for the ADN-S-25-25-A-P are clamping, aligning, stopping and pushing out in assembly and test stations. Mount the ADN-S-25-25-A-P via through-holes, female threads or Festo accessories. For sizing, Festo states 70 g basic weight and 17 g moving mass at 0 mm stroke, plus 30 g and 6 g respectively per 10 mm stroke.
