Compact cylinder double-acting Ø 32 mm stroke 100 mm ADN-32-100-A-P-A - Festo 8173461

Where space in the stroke direction is short, the ADN-32-100-A-P-A fits in: double-acting compact cylinder, 32 mm piston, 100 mm stroke, 483 N advance and 415 N return force at 6 bar. The data below is derived from the type code ADN-32-100-A-P-A and Festo data of the ADN series with a 32 mm piston.

Key benefits

• Double-acting: 483 N on advance, 415 N on return at 6 bar
• Quiet stop: elastic cushioning at both ends absorbs 0.4 J in the end positions
• Sensor-ready: end positions detectable via proximity switch, air port G1/8
• Flexible use: operating pressure 0.6 to 10 bar
• Attachment: piston rod with male thread, 32 mm piston

Applications

On assembly lines the ADN-32-100-A-P-A with a 32 mm diameter handles clamping, stopping and positioning tasks. With 100 mm stroke it also handles longer pushing and feed travel.
