Double-acting compact cylinder Ø 40 mm stroke 40 mm ADN-40-40-I-PPS-A-S2 - Festo 593670

The Festo compact cylinder ADN-40-40-I-PPS-A-S2 moves its load over a 40 mm stroke, the piston measures Ø 40 mm. According to type code ADN-40-40-I-PPS-A-S2, the cylinder is prepared for end-position sensing with proximity switches. Being double-acting, the Ø 40 mm piston is driven by compressed air in both directions.

Benefits at a glance

• Piston Ø 40 mm, stroke 40 mm
• PPS end-position cushioning without adjustment
• Piston rod with female thread
• End positions can be sensed with proximity switches
• Double-acting: force in both directions

Use

The ADN-40-40-I-PPS-A-S2 handles pushing, lifting and ejecting movements over 40 mm in assembly systems, packaging machines and feeding equipment.
