Double-acting compact cylinder Ø 32 mm stroke 40 mm ADN-32-40-I-P-A-TT - Festo 578554

The Festo compact cylinder ADN-32-40-I-P-A-TT moves its load over a 40 mm stroke, the piston measures Ø 32 mm. According to type code ADN-32-40-I-P-A-TT, the cylinder is prepared for end-position sensing with proximity switches. Being double-acting, the Ø 32 mm piston is driven by compressed air in both directions.

Benefits at a glance

• Piston Ø 32 mm, stroke 40 mm
• Elastic end-position cushioning P at both ends
• Piston rod with female thread
• Position detection via proximity switches
• Double-acting: force in both directions

Use

Typical tasks are ejecting, shifting and positioning workpieces over 40 mm, wherever a standard cylinder would be too long.
