Double-acting compact cylinder Ø 100 mm stroke 50 mm ADN-100-50-A-P-A-S2-22K2-S6 - Festo 593453

With a 50 mm stroke and a Ø 100 mm piston, the ADN compact cylinder ADN-100-50-A-P-A-S2-22K2-S6 covers short linear movements. The piston rod with male thread takes the tooling or load. According to type code ADN-100-50-A-P-A-S2-22K2-S6, the cylinder is prepared for end-position sensing with proximity switches.

Benefits

• Piston Ø 100 mm, stroke 50 mm
• Elastic end-position cushioning P at both ends
• Piston rod with male thread
• Position detection via proximity switches
• Double-acting: force in both directions

Applications

Typical tasks are ejecting, shifting and positioning workpieces over 50 mm, wherever a standard cylinder would be too long.
