Compact cylinder double-acting Ø 12 mm stroke 30 mm ADN-S-12-30-I-P - Festo 8076411

Where space in the stroke direction is short, the ADN-S-12-30-I-P fits in: double-acting compact cylinder, 12 mm piston, 30 mm stroke, 68 N advance and 51 N return force at 6 bar.

Benefits

• Force in both directions: theoretical 68 N advance and 51 N return at 6 bar
• Gentle end positions: elastic cushioning rings at both ends, impact energy up to 0.06 J
• Flexible use: operating pressure 1 to 10 bar, any mounting position
• Corrosion resistance class CRC 1: piston rod in high-alloy stainless steel
• Cleanroom and paint shops: class 5 to ISO 14644-1, LABS (PWIS) conformity VDMA24364-B2-L

Applications

With a 12 mm piston, the ADN-S-12-30-I-P suits small-parts handling, electronics assembly and light stoppers. Mount the ADN-S-12-30-I-P via through-holes, female threads or Festo accessories. For sizing, Festo states 26 g basic weight and 3.5 g moving mass at 0 mm stroke, plus 15 g and 2 g respectively per 10 mm stroke.
