5/3-way solenoid valve, centre position closed, G 1/4", 115 V AC, 590 l/min, 2 to 10 bar, 4.1 VA

This 5/3-way solenoid valve controls the air path in a compressed air system. The switching function is centre position closed. The connection is G 1/4". The operating pressure is stated as 2 to 10 bar. The materials are body and spool aluminium, seals NBR, pilot polyamide (glass fibre reinforced).

Advantages

• Materials body and spool aluminium, seals NBR, pilot polyamide (glass fibre reinforced), matched to the intended service.
• Protection class IP 65 at the solenoid coil, suitable for dusty surroundings.
• Temperature range of -10 to +60 °C, which covers use in the machine room as well as outdoors.
• Connection G 1/4" and exhaust G 1/8", so the piping follows the existing line network.
• Control voltage tolerance plus/minus 10 percent, which makes short supply dips uncritical.

Applications

• Sequencing of pneumatic axes with connection G 1/4" in handling equipment.
• Installation in control cabinets with a supply of 115 V AC.
• Control of pneumatic flaps, gates and diverters in conveying equipment.
• Cycled feeding and clamping units in fixture building.
