5/2-way push button valve, Detent, G 1/4", 700 l/min, -0.95 to 12 bar, exhaust 2x G 1/4"

This 5/2-way push button valve is hand operated and switches the air path without auxiliary power. The switching function is Detent. The connection is G 1/4". The operating pressure is stated as -0.95 to 12 bar. The materials are body and spool 1.4436, seals FKM.

Advantages

• Operating pressure of -0.95 to 12 bar, which fixes the permissible working range.
• Materials body and spool 1.4436, seals FKM, matched to the intended service.
• Temperature range of -20 to +180 °C, which covers use in the machine room as well as outdoors.
• Connection G 1/4" and exhaust 2x G 1/4", so the piping follows the existing line network.
• Media oiled and non-oiled compressed air, non-toxic gases (50 µm), so no separate treatment is needed.

Applications

• Control of double-acting cylinders with an air demand up to 700 l/min.
• Sequencing of pneumatic axes with connection G 1/4" in handling equipment.
• Control of pneumatic flaps, gates and diverters in conveying equipment.
• Cycled feeding and clamping units in fixture building.
