Through a nominal size of 5.6 mm this 3/2-way solenoid valve passes 1150 l/min at connection G 1/4". The operating pressure runs from 1.5 to 8 bar. The switching function is Impulse valve.
3/2-way solenoid valve, Impulse valve, G 1/4", 12 V DC, 1150 l/min, nominal size 5.6 mm, 3 W
E.MC
Original product
Net price (excl. VAT)
€81.67
Item
FL-313629
Manufacturer no.
RV 3232-08-12V=
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.RV 3232-08-12V=
EAN4050571715045
Customs tariff number84812090
ConditionNew
Artikel
FL-313629
Frequently Bought Together
A double-acting actuator needs a valve that switches the air path reliably and delivers the required flow. This 3/2-way solenoid valve with connection G 1/4" passes 1150 l/min and is controlled with 12 V DC. The switching function is Impulse valve. The actuator can therefore be switched straight from the machine control without an extra pilot stage.
Advantages
- Control with 12 V DC at a power consumption of 3 W, which relieves the supply when many valves share one cabinet.
- Switching time of below 50 ms, max. 5 switching cycles / sec. (5/3-way: max. 3 switching cycles / sec.), suitable for short machine cycles.
- Nominal size of 5.6 mm, which defines the usable cross section of the switching position.
- Operating pressure of 1.5 to 8 bar, which fixes the permissible working range.
- Materials body and spool aluminium, seals NBR, pilot polyamide, matched to the intended service.
Technical data
| Feature | Value |
|---|---|
| Function | Impulse valve |
| Control voltage | 12 V DC |
| Thread G1 (2x) | G 1/4" |
| Exhaust thread G1 (1x) | G 1/4" |
| Nominal diameter [mm] | 5.6 |
| Flow rate [l/min] | 1150 |
| Power consumption (DC) [W] | 3 |
| Dimensions [mm] | A 175.4, B 40, C 27, D 10.5, E 72.7, F 30, H1 4.3, H2 4.3, J 20, K 70.2, L 35, M 75.7, N 24, O 87.7, P 0, U 70, V 40.5, W 0 |
| Material body and spool | aluminium |
| Material seals | NBR |
| Material pilot | polyamide |
| Temperature range | -5 to +60 °C |
| Operating pressure | 1.5 to 8 bar |
| Media | oiled and non-oiled, filtered compressed air |
| Switching time (at 5 bar) | below 50 ms, max. 5 switching cycles / sec. (5/3-way: max. 3 switching cycles / sec.) |
| Control voltages | Standard: 24 V DC, 230 V AC, other voltages on request |
| Voltage tolerance | plus/minus 10 percent |
| Protection class | IP 65 |
| Service life | min. 40 million switching cycles |
Applications
- Plants operated within the temperature range -5 to +60 °C.
- Replacement of a defective valve of the same type in existing machines.
- Control of double-acting cylinders with an air demand up to 1150 l/min.
- Sequencing of pneumatic axes with connection G 1/4" in handling equipment.
| Weight | 0.410000 |
|---|---|
| Manufacturer | E.MC |
| Hersteller-Nr | RV 3232-08-12V= |
| EAN | 4050571715045 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Function | Impulsventil |
| Flow rate [l/min] | 1150 |
| Leistungsaufnahme (DC) [W] | 3 |
