2/2-way solenoid valve, de-energised closed (NC), G 1/2", 230 V AC, 0 to 16 bar, Kv 65 l/min, 26 VA

This 2/2-way solenoid valve controls the air path in a compressed air system. The switching function is de-energised closed (NC). The connection is G 1/2". The operating pressure is stated as 0 to 16 bar. The materials are body 1.4581 (internal parts 1.4104), seal FKM.

Advantages

• Temperature range of 0 to +80 °C, which covers use in the machine room as well as outdoors.
• Control voltage tolerance plus/minus 10 percent, which makes short supply dips uncritical.
• Media Compressed air, neutral gases, water, neutral low-viscosity media, other media on request, so no separate treatment is needed.
• Kv value of 65 l/min, from which the flow rate for the actual pressure drop can be calculated.
• Mounting position with upright solenoid, de-energised open (NO) also with horizontal solenoid, which has to be observed before installation.

Applications

• Control of pneumatic flaps, gates and diverters in conveying equipment.
• Cycled feeding and clamping units in fixture building.
• Plants operated within the temperature range 0 to +80 °C.
• Replacement of a defective valve of the same type in existing machines.
