Bulkhead tube fitting, bulkhead design, bulkhead thread M 10x1, tube 6x4 mm, PVDF, elbow design

The bulkhead tube fitting brings the bulkhead thread M 10x1 and a tube of 6x4 mm together. The temperature range reaches from -40 °C to +140 °C. The bulkhead design leads the line tightly through a panel or wall.

Benefits

• The temperature range from -40 °C to +140 °C covers cold installation and warm machine surroundings
• PVDF withstands acids and salt solutions in the range from -40 °C to +140 °C
• The bulkhead panel may be up to 11 mm thick
• The design follows connection principle 1 of the range
• Approvals to FDA are documented for the materials
• Union nut and clamping ring allow the joint to be released repeatedly

Technical data

Applications

Water lines on machines, laboratory equipment and dosing technology, plant construction with frequent modification, tube lines in pneumatics.

Standards and conformity

The following approvals are documented for the materials used: FDA.
