Solenoid valve 2x 3/2 normally closed, monostable, 14 mm, G1/8 VUVG-SK14-T32C-AT-G18-1H2L-W1-S - Festo 596065

Festo ✓ Original product Brand new

VUVG solenoid valve with valve function 2x 3/2 normally closed, monostable in valve size 14 mm. Port G1/8, 24 V DC coil, reset by pneumatic spring, internal pilot air.

Net
€72.08
excl. VAT
Item FES-596065
Manufacturer no. VUVG-SK14-T32C-AT-G18-1H2L-W1-S
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The solenoid valve VUVG-SK14-T32C-AT-G18-1H2L-W1-S contains two separately actuated 3/2-way functions, both closed in the normal position. VUVG series, valve size 14 mm.

Benefits

  • Size: Valve size 14 mm, working port G1/8.
  • Voltage: 24 V DC.
  • Reset: Pneumatic spring, internal pilot air.
  • Manual override: Detenting, non-detenting.

Application

The VUVG-SK14-T32C-AT-G18-1H2L-W1-S switches single-acting actuators or blow-air circuits. The pilot stage is supplied internally. Weight 0.09 kg. The data is derived from order type VUVG-SK14-T32C-AT-G18-1H2L-W1-S, see the Festo datasheet for further values.

Technical data

TypeVUVG-SK14-T32C-AT-G18-1H2L-W1-S
Festo part number596065
Valve function2x3/2-way, closed, monostable
Type of actuationElectrical
Valve size14 mm
Pneumatic working portG1/8
Operating voltage24 V DC
Type of resetPneumatic spring
Manual overrideDetenting, non-detenting
Pilot air supplyInternal
Weight0.09 kg
ManufacturerFesto
Hersteller-NrVUVG-SK14-T32C-AT-G18-1H2L-W1-S
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/8
Function2x3/2 closed monostable
Actuation typeElectrical
SeriesVUVG
Pneumatic connectionG1/8
