Solenoid valve 5/2-way monostable, valve size 14 mm, G1/8 VUVG-S14-M52-AZH-G18-1H2L - Festo 610483

Festo ✓ Original product Brand new

The solenoid valve VUVG-S14-M52-AZH-G18-1H2L with 5/2-way monostable function and 14 mm valve size controls double-acting cylinders and actuators. Working ports G1/8. Operating medium compressed air to ISO 8573-1:2010 [7:4:4].

Net
€75.14
excl. VAT
Item FES-610483
Manufacturer no. VUVG-S14-M52-AZH-G18-1H2L
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Valve function 5/2-way monostable at 14 mm valve size: the Festo solenoid valve VUVG-S14-M52-AZH-G18-1H2L controls double-acting cylinders and actuators. Without a signal the 5/2-way valve returns to its normal position, so a double-acting cylinder moves to a defined position.

Benefits

  • Valve size 14 mm for compact valve arrangements
  • Working ports G1/8
  • Valve function 5/2-way monostable

Applications

The operating medium is compressed air to ISO 8573-1:2010 [7:4:4]. Mounting of the VUVG-S14-M52-AZH-G18-1H2L: on manifold rail, with through-hole.

Technical data

FeatureValue
TypeVUVG-S14-M52-AZH-G18-1H2L
Festo part number610483
SeriesVUVG
Valve function5/2-way monostable
Type of actuationElectrical
Valve size14 mm
DesignPiston spool
Exhaust air functionCan be throttled
Sealing principleSoft
Mounting positionAny
Type of pilotingPiloted
Duty cycle100 %
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Type of mountingOn manifold rail, with through-hole
Pneumatic port 1G1/8
Pneumatic port 2G1/8
Pneumatic port 3G1/8
Pneumatic port 4G1/8
Pneumatic port 5G1/8
Seal materialHNBR, NBR
Housing materialWrought aluminium alloy
ManufacturerFesto
Hersteller-NrVUVG-S14-M52-AZH-G18-1H2L
Zolltarifnummer90330090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
ThreadG 1/8
MediumCompressed air
Function5/2 monostable
Actuation typeElectrical
Pneumatic connectionG1/8
