Straight male push-in adaptor, 5/32" tube OD, 1/8 NPT, Pneufit 12 - Norgren 124250218
Fast tube connection by simply pushing the tube in: the Norgren 124250218 straight male push-in adaptor for 5/32" tube OD with 1/8 NPT thread. The 124250218 at a glance: operating pressure -0.9 to 18 bar, temperature range -20 to 80 °C, nickel-plated brass body.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 124250218 is a straight male push-in adaptor for 5/32" tube OD with 1/8 NPT thread from the Pneufit 12 range. For the 124250218 Norgren states an operating pressure of -0.9 to 18 bar and a temperature range of -20 to 80 °C. The body of the 124250218 is made of nickel-plated brass, the seals of nitrile rubber (NBR).
Benefits
- Usable from -0.9 bar (vacuum) up to 18 bar
- Temperature range -20 to 80 °C
- Inch male thread 1/8 NPT
- Hexagon size 1/8"
- For quick and simple assembly of pneumatic circuits
- Positive tube connection
Applications
The Norgren 124250218 connects compressed-air lines in machines, systems and pneumatic controls.
Technical data
| Manufacturer part number | 124250218 |
|---|---|
| Manufacturer | Norgren |
| Product type | Straight male push-in adaptor |
| Product line | Pneufit 12 |
| Shape | straight |
| Tube OD | 5/32" |
| Male thread | 1/8 NPT |
| Hexagon size | 1/8" |
| Operating pressure | -0.9 to 18 bar |
| Temperature range | -20 to 80 °C |
| Medium | Compressed air |
| Body material | nickel-plated brass |
| Seal material | nitrile rubber (NBR) |
| RoHS | compliant |
| Country of origin | Italy |
| Customs tariff number | 74122000 |
| Weight | 0.001 kg |
| Hersteller-Nr | 124250218 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | Gerade |
| Thread | NPT 1/8 |
| Housing material | Nickel-plated brass |
| Thread type | External thread |
| Betriebsdruck max [bar] | 18 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
