Tube support insert for compression fitting, 8/6 mm tube - Norgren 430330806
Norgren 430330806 is a tube support insert from the 43 series for 8/6 mm tube. The support insert supports the 8/6 mm tube from the inside so that it does not collapse when the fitting is tightened.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Norgren 430330806 is a tube support insert from the 43 series for 8/6 mm tube. The support insert supports the 8/6 mm tube from the inside so that it does not collapse when the fitting is tightened.
The support insert is made of brass and is designed for compressed air at -0.9 to 100 bar and across a temperature range of -40 to 200 °C.
Benefits
- Pressure range -0.9 to 100 bar
- Temperature range -40 to 200 °C
- Rugged and durable
- Supplied assembled with tubing sleeves, nuts and seals
Applications
The support insert serves as a spare or assembly part for Norgren fittings of the matching size.
Standards and compliance
According to the manufacturer, Norgren 430330806 is RoHS compliant.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 430330806 |
| Product type | Tube support insert for compression fitting, 8/6 mm tube |
| Series | 43 |
| Connection type | compression |
| Tube OD | 8 mm |
| Tube ID | 6 mm |
| Body material | brass |
| Medium | compressed air |
| Operating pressure | -0.9 to 100 bar |
| Temperature range | -40 to 200 °C |
| Dimensions L x W x H | 16.5 x 7 x 7 mm |
| Customs tariff number | 76161000 |
| Weight | 0.001 kg |
| Hersteller-Nr | 430330806 |
| Zolltarifnummer | 76161000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Tube OD [mm] | 8 |
| Housing material | Brass |
| Betriebsdruck max [bar] | 100 |
| Temperaturbereich | -40-200 °C |
