VP300, 3 Port Pilot Operated Poppet - SMC VP344K-6DUD1-A
Body Style: 4 (Base Mounted) Valve Option: Standard (Internal pilot) Pressure Specification: K [High-pressure type (1.0 MPa)] Coil Specification: Standard Rated Voltage: 6 (12V DC) Electrical Entry: D (DIN terminal, With connector) Light and Surge Voltage Suppressor: U [With light/surge voltage suppressor (Non-polar)] Manual Override: D (Push-turn Locking Slotted Type) Port Size: Without Sub-plate Thread: Rc (PT) Actuation: A (Normally Closed) Option: None Made to Order: None
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
High flow capacity:Cv1.0 (VP300), Cv2.3 (VP500), Cv4.0 (VP700). Low power consumption: 1.8W(DC).Possible to use as either selector valve or divider valve.Changeable from normallyclosed style to normally open style. Vacuum applicable: Up to -101.2kPa.
Technical data
| Weight | 0.1 kg |
|---|---|
| Manufacturer | SMC |
| Hersteller-Nr | VP344K-6DUD1-A |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | SMC Deutschland GmbH Boschring 13-15 DE-63329 Egelsbach www.smc.eu |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
