VP50 series proportional pressure control valve, 1/4 NPT, 0-10 bar, 4-20 mA - Norgren VP5010PK411H00
Controls pressure or flow steplessly from the control signal. The VP50 series proportional pressure control valve Norgren VP5010PK411H00 accepts an inlet pressure up to 12 bar and is suitable for compressed air.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Proportional valves and converters turn an electrical signal into pressure or flow without steps. The VP50 series proportional pressure control valve Norgren VP5010PK411H00 runs on an operating voltage of 24 V DC and is suitable for compressed air.
Benefits
- Closed loop air piloted proportional control valve
- Fast response time
- Low power consumption
- Port size 1/4 NPT
- Outlet pressure adjustable from 0 to 10 bar
- Temperature range 0 to 50 °C
Applications
The valve is used in clamping, pressing and dosing tasks with variable pressure.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 13,500,000 cycles.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren VP5010PK411H00 |
| Series | VP50 |
| Valve function | 3/2 |
| Port size | 1/4 NPT |
| Maximum inlet pressure | 12 bar |
| Adjustable outlet pressure | 0 to 10 bar |
| Medium | Compressed air |
| Temperature range | 0 to 50 °C |
| Body material | Aluminium |
| Electrical connection | M12 x 1 |
| Operating voltage | 24 V DC |
| Control signal | 4 to 20 mA |
| Protection class | IP65 |
| b10 value | 13,500,000 cycles |
| Height | 56.3 mm |
| Width | 50 mm |
| Length | 119.3 mm |
| Weight | 0.55 kg |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | VP5010PK411H00 |
| Zolltarifnummer | 90322000 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Certification | DIN EN ISO 13849 |
