VP23 series proportional pressure control valve, 16mm, 0-2 bar, IO-Link - Norgren VP2302BELL1MB200
Controls pressure or flow steplessly from the control signal. The VP23 series proportional pressure control valve Norgren VP2302BELL1MB200 reaches protection class IP65 and is manufactured in Czechia.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Proportional valves and converters turn an electrical signal into pressure or flow without steps. The VP23 series proportional pressure control valve Norgren VP2302BELL1MB200 accepts an inlet pressure up to 7 bar and weighs 1.7 kg.
Benefits
- Microprocessor controlled closed loop controller
- Variable pressure control
- USB interface for use with the VP-Tool software
- Outlet pressure adjustable from 0 to 2 bar
- Flow 3500 l/min
- Temperature range -5 to 50 °C
Applications
Typical installations are test benches, coating plants and machine tools.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 12,000,000 cycles.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren VP2302BELL1MB200 |
| Series | VP23 |
| Valve function | 3/2 |
| Valve technology | Spool |
| Spool and sleeve | Aluminium |
| Mounting | Manifold |
| Nominal diameter | 16 mm |
| Maximum inlet pressure | 7 bar |
| Adjustable outlet pressure | 0 to 2 bar |
| Flow | 3500 l/min |
| Medium | Compressed air and gases |
| Temperature range | -5 to 50 °C |
| Body material | Aluminium |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | M12 x 1 |
| Operating voltage | 18 to 32 V DC |
| Control signal | IO-Link |
| Protection class | IP65 |
| b10 value | 12,000,000 cycles |
| Height | 132.6 mm |
| Width | 70 mm |
| Length | 166.5 mm |
| Weight | 1.7 kg |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | VP2302BELL1MB200 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Certification | DIN EN ISO 13849 |
