VP23 series proportional pressure control valve, 8mm, 0-2 bar, IO-Link - Norgren VP2302BDLL1MB200

Proportional valves and converters turn an electrical signal into pressure or flow without steps. The VP23 series proportional pressure control valve Norgren VP2302BDLL1MB200 regulates the outlet pressure in the range 0 to 2 bar and reaches protection class IP65.

Benefits

• Microprocessor controlled closed loop controller
• Variable pressure control
• USB interface for use with the VP-Tool software
• Outlet pressure adjustable from 0 to 2 bar
• Flow 850 l/min
• Temperature range -5 to 50 °C

Applications

The valve is used in clamping, pressing and dosing tasks with variable pressure.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 12,000,000 cycles.
