VP23 series proportional pressure control valve, 8mm, 0-16 bar, IO-Link - Norgren VP2316BDLL1MB200
Responds quickly to set point changes. The VP23 series proportional pressure control valve Norgren VP2316BDLL1MB200 is suitable for compressed air and gases and seals with nitrile rubber (nbr).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Proportional valves and converters turn an electrical signal into pressure or flow without steps. The VP23 series proportional pressure control valve Norgren VP2316BDLL1MB200 has a body made of aluminium and covers the temperature range -5 to 50 °C.
Benefits
- Microprocessor controlled closed loop controller
- Variable pressure control
- USB interface for use with the VP-Tool software
- Outlet pressure adjustable from 0 to 16 bar
- Flow 3000 l/min
- Temperature range -5 to 50 °C
Applications
Typical installations are test benches, coating plants and machine tools.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 12,000,000 cycles.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren VP2316BDLL1MB200 |
| Series | VP23 |
| Valve function | 3/2 |
| Valve technology | Spool |
| Spool and sleeve | Aluminium |
| Mounting | Manifold |
| Nominal diameter | 8 mm |
| Maximum inlet pressure | 17 bar |
| Adjustable outlet pressure | 0 to 16 bar |
| Flow | 3000 l/min |
| Medium | Compressed air and gases |
| Temperature range | -5 to 50 °C |
| Body material | Aluminium |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | M12 x 1 |
| Operating voltage | 18 to 32 V DC |
| Control signal | IO-Link |
| Protection class | IP65 |
| b10 value | 12,000,000 cycles |
| Height | 113.3 mm |
| Width | 55 mm |
| Length | 136 mm |
| Weight | 1.1 kg |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | VP2316BDLL1MB200 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Certification | DIN EN ISO 13849 |
