Solenoid valve 3/2-way single solenoid, closed G1/4 ATEX VOFD-L50T-M32-MN-G14-10-R16-F10 - Festo 8201899
The VOFD-L50T-M32-MN-G14-10-R16-F10 switches compressed air as a 3/2-way valve (single solenoid, closed) and reaches 493 l/min standard nominal flow rate. Ratings: 0 to 10 bar operating pressure, G1/4 port and 51 mm width. For hazardous areas: Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The solenoid valve VOFD-L50T-M32-MN-G14-10-R16-F10 works as a 3/2-way valve (single solenoid, closed) and reaches 493 l/min standard nominal flow rate at 0 to 10 bar operating pressure. Further ratings: G1/4 port, 51 mm width and IP65 protection.
Benefits at a glance
- Flow: 493 l/min standard nominal flow rate at only 51 mm width
- Pressure range: 0 to 10 bar
- Switching times: 40 ms on, 60 ms off
- Functional safety: safe exhausting, suitable up to SIL 3
- Explosion protection: Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX)
- Rugged: IP65 protection, corrosion resistance class 1
Applications
The VOFD-L50T-M32-MN-G14-10-R16-F10 is designed for hazardous areas: Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX). In safety-related control systems it performs safe exhausting up to SIL 3. Operating medium for the VOFD-L50T-M32-MN-G14-10-R16-F10: compressed air to ISO 8573-1:2010 [7:2:2].
Technical data
| Type | VOFD-L50T-M32-MN-G14-10-R16-F10 |
|---|---|
| Festo part number | 8201899 |
| Valve function | 3/2-way, single solenoid, closed |
| Type of actuation | electrical |
| Width | 51 mm |
| Standard nominal flow rate | 493 l/min |
| pneumatic working port | G1/4 |
| Operating pressure | 0 to 10 bar |
| Design | directly actuated poppet valve |
| Reset method | mechanical spring |
| Degree of protection | IP65 |
| Certificate issuing authority | TÜV 968/V 1251.02/24 |
| Nominal size | 5 mm |
| Sealing principle | soft |
| Mounting position | any |
| Manual override | none |
| Type of piloting | direct |
| Flow direction | reversible |
| Safety function | safe exhausting |
| Safety Integrity Level (SIL) | up to SIL 3 high demand mode, to SIL 3 Low Demand mode |
| Suitability for vacuum | ja |
| b value | 0.25 |
| C value | 2 l/sbar |
| Flow rate Kv pressurisation | 0.36 m³/h |
| Flow rate Kv exhaust | 0.36 m³/h |
| Standard nominal flow rate 2-3 | 429 l/min |
| Switching time off | 60 ms |
| Switching time on | 40 ms |
| Explosion protection | Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX) |
| Operating medium | compressed air to ISO 8573-1:2010 [7:2:2] |
| Extended ambient temperature | -25 - 60 °C, low demand mode |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-Zone III |
| Media temperature | -25 to 60 °C |
| Ambient temperature | -25 to 60 °C |
| Product weight | 750 g |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | G1/4 |
| Pneumatic connection, port 3 | G1/4 |
| Note on materials | RoHS compliant |
| Material seals | NBR |
| Material housing | brass |
| Weight (shipping) | 0.85 kg |
| Weight | 0.85 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VOFD-L50T-M32-MN-G14-10-R16-F10 |
| EAN | 4052568643027 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/4 |
| Nominal size DN [mm] | 5 |
| Seal material | NBR |
| Housing material | Brass |
| Medium | Compressed air |
| Function | 3/2 closed monostable |
| Flow rate [l/min] | 493 |
| Actuation type | Electrical |
| Series | VOFD |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1/4 |
| Protection rating | IP65 |
