Solenoid valve 5/2-way single solenoid 1/4 NPT ATEX VOFC-L-M52-M-N14-FN - Festo 8122931
Festo solenoid valve VOFC-L-M52-M-N14-FN as a 5/2-way valve (single solenoid) for electrical actuation. Designed for 2.5 to 8 bar operating pressure, 1/4 NPT port and IP65 protection. Suitable for Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Rated for 2.5 to 8 bar operating pressure, the solenoid valve VOFC-L-M52-M-N14-FN switches as a 5/2-way valve (single solenoid). It also offers 1/4 NPT port and IP65 protection.
Benefits at a glance
- Pressure range: 2.5 to 8 bar
- Safety function: safe exhausting
- Explosion protection: Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX)
- Rugged: IP65 protection, corrosion resistance class 4
Applications
The VOFC-L-M52-M-N14-FN is designed for hazardous areas: Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX). Safety function of the VOFC-L-M52-M-N14-FN: safe exhausting.
Technical data
| Type | VOFC-L-M52-M-N14-FN |
|---|---|
| Festo part number | 8122931 |
| Valve function | 5/2-way, single solenoid |
| Type of actuation | electrical |
| Type of piloting | piloted |
| Reset method | mechanical spring |
| Pneumatic connection, port 1 | 1/4 NPT |
| Pneumatic connection, port 2 | 1/4 NPT |
| Safety function | safe exhausting |
| Material housing | ematal coated aluminium |
| Material seals | NBR |
| Flow direction | non-reversible |
| Mounting position | any |
| Operating pressure | 2.5 to 8 bar |
| Degree of protection | IP65 |
| Explosion protection | Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX) |
| Corrosion resistance class CRC | 4 - Very high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-Zone III |
| Note on materials | RoHS compliant |
| Weight (shipping) | 0.55 kg |
| Weight | 0.55 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VOFC-L-M52-M-N14-FN |
| EAN | 4052568478629 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | NPT 1/4 |
| Seal material | NBR |
| Function | 5/2 monostable |
| Actuation type | Electrical |
| Series | VOFC |
| Betriebsdruck max [bar] | 8 |
| Pneumatic connection | NPT 1/4 |
| Protection rating | IP65 |
