Solenoid valve 5/2-way single solenoid G1/4 VOFC-L-M52-M-FG14-PFU6-F19A-11-1K4-EX4A - Festo 593426

Festo ✓ Original product Brand new

Festo solenoid valve VOFC-L-M52-M-FG14-PFU6-F19A-11-1K4-EX4A as a 5/2-way valve (single solenoid) for electrical actuation. Designed for G1/4 port and 40 mm width. Mounts directly on the quarter-turn actuator via the NAMUR interface.

Net
€652.72
excl. VAT
Item FES-593426
Manufacturer no. VOFC-L-M52-M-FG14-PFU6-F19A-11-1K4-EX4A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo solenoid valve VOFC-L-M52-M-FG14-PFU6-F19A-11-1K4-EX4A is an electrically actuated 5/2-way valve (single solenoid). It also offers G1/4 port and 40 mm width.

Key benefits

  • Compact: 40 mm width
  • Safety function: safe exhausting
  • Interface: NAMUR connection pattern

Applications

Thanks to the NAMUR connection pattern, the VOFC-L-M52-M-FG14-PFU6-F19A-11-1K4-EX4A mounts directly on pneumatic quarter-turn actuators without tubing between valve and actuator. Safety function of the VOFC-L-M52-M-FG14-PFU6-F19A-11-1K4-EX4A: safe exhausting.

Technical data

TypeVOFC-L-M52-M-FG14-PFU6-F19A-11-1K4-EX4A
Festo part number593426
Valve function5/2-way, single solenoid
Type of actuationelectrical
Width40 mm
Type of pilotingpiloted
Pilot air supplyinternal
Designpiston gate valve
Reset methodmechanical spring
Pneumatic connection, port 1G1/4
Pneumatic connection, port 2connection pattern to NAMUR, flange 1/4
Safety functionsafe exhausting
Material housingematal coated aluminium
Material sealsNBR
Sealing principlesoft
Flow directionnon-reversible
Mounting positionany
Weight (shipping)1 kg
Weight1 kg
ManufacturerFesto
Hersteller-NrVOFC-L-M52-M-FG14-PFU6-F19A-11-1K4-EX4A
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/4
Seal materialNBR
Function5/2 monostable
Actuation typeElectrical
SeriesVOFC
Pneumatic connectionG1/4
