Valve terminal without valves, 20 stations, PROFIBUS DP, 24 V DC, IP 65, aluminium

The valve terminal is supplied without valves and accepts up to 20 stations that are addressed via PROFIBUS DP. Instead of many single wires, one bus cable to the controller is enough, which cuts wiring effort and sources of error in the cabinet. Every valve solenoid runs on 24 V DC and draws only 1.3 W, with an LED status indicator and a protective circuit provided per station. Operating pressure ranges from 3 to 8 bar, and 0 to 8 bar are possible when the separate pilot air port is used. A body of aluminium and plastic with NBR seals covers -10 to +50 °C at degree of protection IP 65.

Benefits

• 20 stations on one bus cable via PROFIBUS DP instead of individually routed control lines.
• Power input of only 1.3 W per valve solenoid at 24 V DC.
• LED status indicator and protective circuit on each of the 20 stations.
• Degree of protection IP 65 with a housing of aluminium and plastic plus NBR seals.
• Exhaust per channel through a G 3/8" port on top and one at the face end, pilot exhaust through two G 1/8" ports.
• Pressure separation inside the terminal and air supply from both ends are possible.

Applications

• Field-mounted valve islands in PROFIBUS DP systems with up to 20 actuators.
• Packaging and handling machines with a dense arrangement of cylinders.
• Applications exposed to splash water in line with degree of protection IP 65.
• Plant sections needing two pressure levels that use the pressure separation feature.
• Machines with separate pilot air supply that have to operate from 0 bar upwards.

Standards and conformity

The terminal meets degree of protection IP 65 and is controlled via PROFIBUS DP. A tolerance of ± 10 % applies to the 24 V DC control voltage.
