Sub-base G1/8, valve size 12 mm VABS-K2-12S-20-G18-P - Festo 8186871

Festo ✓ Original product Brand new

The sub-base VABS-K2-12S-20-G18-P carries a valve and provides its pneumatic ports. Size 12, tightening torque 0.33 Nm. Material: PEEK, CRC 0, RoHS compliant.

Net
€89.25
excl. VAT
Item FES-8186871
Manufacturer no. VABS-K2-12S-20-G18-P
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The sub-base VABS-K2-12S-20-G18-P carries a valve and provides its pneumatic ports. Fluid connection: female thread G1/8. The VABS-K2-12S-20-G18-P is made of PEEK. Corrosion resistance class 0. Size 12.

Benefits

  • Port thread: G1/8
  • Tightening torque: 0.33 Nm
  • Material: PEEK, CRC 0
  • PWIS-free: VDMA 24364 zone III

Applications

The VABS-K2-12S-20-G18-P is mounted with through-hole, any mounting position. The valve is attached with female thread. Tightening torques: valve mounting max. 0.33 Nm, fitting max. 7 Nm and max. tightening torque 0.6 Nm. Operating medium: liquid and gaseous media, observe resistance of materials that come into contact with the media. Ambient and medium temperature 0 to 50 °C each. Design: connection direction on the side.

Technical data

TypeVABS-K2-12S-20-G18-P
Festo part number8186871
Size12
Nominal size2 mm
Valve size12 mm
Fluid connectionFemale thread G1/8
Mounting positionAny
DesignConnection direction on the side
Max. number of valve positions1
Flow directionNon-reversible
Operating mediumLiquid media, gaseous media
Note on operating and pilot mediumObserve resistance of materials that come into contact with the media
Corrosion resistance class CRC0 - No corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-20 to 70 °C
Suitable for use with foodSee supplementary material information
Medium temperature0 to 50 °C
Ambient temperature0 to 50 °C
Max. tightening torque for valve mounting0.33 Nm
Max. tightening torque for fitting7 Nm
Max. tightening torque0.6 Nm
Product weight31 g
Mounting type sub-baseWith through-hole
Mounting type valveWith female thread
Note on materialsRoHS compliant
Material sub-basePEEK
Weight0.034 kg
ManufacturerFesto
Hersteller-NrVABS-K2-12S-20-G18-P
EAN4052568635251
Zolltarifnummer84819000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/8
Nominal size DN [mm]2
SeriesVABS
Pneumatic connectionG1/8
Temperaturbereich0-50 °C
Temperature (max.)50
