Manifold rail for 8 valves, 16 mm grid, G1/4 VABM-L1-14WB-G14-8-GR - Festo 596214
Groups 8 valves on a 16 mm grid with one shared compressed-air supply. Supply port 1 in G1/4. Type VABM-L1-14WB-G14-8-GR, Festo part number 596214.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With 8 valve positions on a 16 mm grid, the manifold rail VABM-L1-14WB-G14-8-GR forms the base of a compact valve group. Lines connect via supply port 1 in G1/4.
Benefits
- Valve positions: 8 positions on a 16 mm grid
- Supply: Port 1 in G1/4
- Festo part number: 596214
Applications
Type VABM-L1-14WB-G14-8-GR and Festo part number 596214 define the version clearly, for example when reordering or extending an existing valve group.
Technical data
| Type | VABM-L1-14WB-G14-8-GR |
|---|---|
| Festo part number | 596214 |
| Grid dimension | 16 mm |
| Pneumatic connection, port 1 | G1/4 |
| Number of valve positions | 8 |
| Weight (shipping) | 1.8 kg |
| Weight | 1.8 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VABM-L1-14WB-G14-8-GR |
| Zolltarifnummer | 84819000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/4 |
| Design | Manifold terminal strip |
| Anzahl Stationen [Stk] | 8 |
| Series | VABM |
| Pneumatic connection | G1/4 |
